Home  /  Plumbing  / Installing a new bathroom with a toilet, sink, and tub is a challenging do-it-yourself project. You'll need a thorough understanding of plumbing systems and techniques. Developing a sound plan and working with a good helper will help ensure you get everything right. Installing a Pedestal Sink Hooking Up a Shower or Tub Faucet Installing a Whirlpool Tub Running Drain and Vent Lines Building a Shower Enclosure Running Copper Supply Lines Installing a Luxury Shower Installing a Bathroom Vanity Sink Building a Wet Wall Getting a handle on the plumbing The following sections show how to install the three major bathroom plumbing fixtures in a common configuration. You'll find quite a few variations on this basic arrangement. Your situation may call for pipe runs that differ from those shown, so you may need to develop a unique plan that suits your home.You'll need a good understanding of the basic skills and techniques of plumbing.

Pay special attention to the drain vents and make sure you use pipe types and sizes that conform to code. If possible hire a professional plumber to spend an hour or two giving you advice. This modest investment could save time and money later. Whether you are remodeling an existing bathroom or installing one in a new addition, you will need carpentry skills. Modifying the framing sometimes can make the plumbing work easier. Plan and install the plumbing so it damages joists and studs as little as possible; reinforce any framing members that have been compromised. It's usually best to run any electrical lines after the plumbing has been installed.Sarah Wilson / Getty Images, 2014, Scripps Networks, LLC. Bathtub dimensions can vary. Before you buy, check the dimensions of a new tub so that it will fit in the same spot as the old one. Another consideration with very large tubs is whether you will be able to maneuver it through your home to the bathroom. Room to work is also important — especially in smaller bathrooms.

It will sometimes be necessary to remove the other bathroom fixtures in order to remove an old bathtub and install a new one.Puppies For Adoption In San Luis Obispo Connecting the water supply to a bath is much the same as for a basin. Red Moroccan CurtainsThe main difference when installing a bath is that it may be large and heavy, and access to the plumbing can be difficult.Mirror Mounting Hinges 2007 Dorling Kindersley Limited Decorative cast-iron tubs may be candidates for reclamation. If not, these heavy items can be broken up using a sledgehammer and all of the material recycled. When you do this, drape a drop cloth over the old tub to stop flying debris and be sure to wear protective goggles, ear protectors and gloves.

When installing a cast-iron tub, ensure that its weight is evenly distributed across several floor joists. Planks of wood underneath the tub feet can help spread the weight. In some cases, you may need to reinforce the joists below. Before you begin, make sure you have enough room to fit the bathtub through the doorway. Turn off the water supply. After the water has been turned off, open a faucet below the tub level to drain the water supply lines. Remove the faucet, the drain, and the spout. If your bathtub is sandwiched between two walls, with the faucet and shower head located on one wall, you may be able to disconnect the piping and then pull the tub out. If this doesn’t work, you may have to remove a section of the wall around the bathtub, cut the piping, and remove the bathtub through the wall. If your bathtub is freestanding, removal is somewhat easier. After disconnecting the piping, you should simply be able to lift the tub out. Before installing a new bathtub, make sure that your selection is an exact fit into the old bathtub space.

Make sure it is apron-styled or drop-in, and that the drain is on the same side, because bathtubs can have right-hand or left-hand drains. If the bathtub is not an exact fit, the piping will have to be modified for the new bathtub. If it is an exact fit, you’ll follow the same steps for removing the old bathtub, just in reverse. You may need to repair the wall surface so it rests on the flange of the new tub. Always use cement backerboard under tiles in the bathtub or shower areas for moisture protection and to prevent a possible mold problem. Regular drywall is not rated to handle extreme moisture. Measure and mark the location of the bathtub's ledger (Image 1). Attach the ledger board, which will support the bathtub’s ledger (Image 2). While the tub is on its side, dry fit the drain and water supply pipes (Image 1). Install the rubber gasket on the bathtub overflow tube, and attach it to the tub (Image 2). Use the fittings provided to attach the stopper retaining bracket (Image 3).

Apply a ring of plumber's putty around the drain flange (Image 4). Attach the drain to the bathtub, using screws to secure it in place (Image 5). Use needle pliers to connect the stopper chain mechanism to the stopper fit (Image 1). Route the chain from the stopper fit through the bathtub, adjacent to the retaining bracket (Image 2). Secure the stopper fit in place using the fittings provided (Image 3). Lift the bathtub in place and insert the drain and water pipe assembly into the drain (Image 4). Nail the flange to the wall studs (Image 1). Make sure the bathtub is level, then finish the surrounding walls (Image 2). With time and use, a bathtub stopper may cease to block the water flow efficiently. Remove the stopper face plate from wall. Expose the mechanism and then adjust the chain to fit.• Before removing the tub, shut off the water supply. If your bathroom doesn't have a separate cutoff valve, turn off the water to the entire house.

• Open a valve at a lower level in your home to relieve any remaining pressure in the lines. • Tub drains have different components that first need to be removed, so procedures on this step may vary. The one here has a stopper that unscrews, allowing you to access the drain flange at the bottom of the tub. • Use a tool designed for tub drain removal to remove the drain flange. • Use the screwdriver to disconnect and remove the waste and overflow valve cover on the side of the tub. • Remove the tub spout since this will be on a portion of the wall you'll be cutting away. Some spouts have a setscrew that holds them in place. If you don't find one, your spout should just twist off by turning it counterclockwise. • To disconnect the drain, you need to gain access to the underside of the tub, either from behind the wall or through the ceiling or floor below the bathroom. • Use a pair of channel lock pliers to disconnect the pipes below the tee where the drain and overflow valve meet.

If your fittings on your bathtub drain are galvanized steel, you may need a penetrating lubricant like PB Blaster to loosen the joints first. • Once you've loosened the nut connecting the drain pipe, unscrew it the rest of the way by hand and lift out the entire section. • Cut out a section of drywall approximately 6 inches above the tub on each of the three sides. To make repairing the wall easier, measure a standard distance up from the top of the tub. • Use a straight edge to mark a guideline all the way around. Cut along the line with a drywall saw and remove the section between the line and the tub all the way down to the studs. • Clear everything away so you have access to the screws or nails attaching the tub flange to the studs.• Remove the screws or nails all the way around the top and sides of the tub with a pry bar. Also remove any trim moulding from the sides of the alcove. • Cut away any caulk between the tub and floor with a utility knife.

Safety: You need a helper for these next few steps. • One person should lift up the front edge of the tub, while another slides a couple of 1 x 4s underneath it to get it off the floor. • Slide the tub out of the alcove using the 1 x 4s as skids. • Remove any stringer supports left on the wall. The stringer is the crosspiece that supports the edge of the tub. • With the alcove now exposed, clean the area and remove any nails or debris that's left over. Tip: Remember to wear protective ear and eye gear when removing any type of tub. Check with your local sanitation company for specific details on disposing your old tub. • How you dispose of the old tub will depend on the type it is. Cast iron tubs should be broken up with a sledgehammer. Because of the sheer weight, do this in the bathroom so you can remove the tub in sections. • All other types of bathtub material are relatively light. The tub can be removed whole as long as you have some help.

Steel, composite or fiberglass tubs can be cut up with a reciprocating saw. Porcelain over steel tubs should be disposed of whole. • Before selecting a new tub, measure the width and depth of your alcove. Most bathtubs are 5 feet long, and either 30 or 32 inches wide. • To find out what kind of tub you need, face the alcove. The side of the alcove that holds the drain opening determines what type of tub you need: If the drain opening is on the left side, you should look for a left drain tub. If it's on the right, you need a right drain tub. • If the tub you're putting in is a different size or orientation than your old one, re-locate the rough-in plumbing. • Make sure the subfloor is level, and if necessary, use a leveling compound to even out the surface. (note- numbers are off from this point forward) Tip: Before installation, check the tub over and report any damage to the manufacturer. Because the porcelain can fracture, keep your new tub safely packaged until you're ready to install it.

Cut out a section of the cardboard to set inside the tub to help protect the surface while you work. Use another piece of cardboard to protect the exposed porcelain side as well. • Many tubs have a sound deadening and leveling pad on the underside, and this pad needs to rest fully on the subfloor. • Use your helper to carefully set the tub onto the skids and slide it into place in the alcove. • Once it's in position, check to see if the tub is level, and if necessary use shims to even it out. • Take a pencil and mark a reference line on the studs all the way around on all three sides. After doing this, take out the tub and set it aside. • Since you've already marked the top edge of the flange on the studs, you'll need to allow for the height of the flange to install the stringer. • Take the height and measure that same distance below the reference line on each stud. This new mark will serve as the top edge of the stringer you'll install. • Cut a 2 x 4 the length of your tub, and use deck screws to attach it to the studs on the new reference marks.

• To put in the drain, turn the tub on its side and install it according to the manufacturer's instructions. • Take a bit of plumber’s putty, roll it in your hands and place it on the underside of the drain flange. • Position the drain shoe on the underside of the tub, and screw the drain flange into the threads. Tighten it down completely with the drain tool and remove any excess putty. • To connect the overflow valve, place the rubber gasket onto the overflow elbow, and position it behind the tub. • Attach the cover plate inside the tub to the overflow elbow and gasket behind the tub. • Connect the overflow pipe and drain pipe with a tee where the two meet. • Install the drain strainer onto the flange. • Carefully move the tub back into place. As you do, make sure not to disrupt the drain assembly you just attached. When it's in position, the flange should rest on the stringer that was just installed along the back wall. • Make sure the drain and overflow plumbing coming out of your tub is aligned with the rough-in drain outlet in your bathroom.
